UNIFIED |
Thread Size |
Type |
Thread Code |
Length "L" +.002-.005 |
Min.Sheet Thickness |
Blind Mounting Hole Dia |
Min. Depth Of Blind Hole (4) |
Min. Depth Full Thread F |
A |
B Max. |
C |
H |
Min.Dist Hole C/L To Edge |
|||||||
|
Stainless Steel |
.187 |
.250 |
.312 |
.375 |
.500 |
.625 |
.750 |
.100 |
||||||||||||
|
.112-40(#4-40) |
CSS |
440 |
3(1) |
4(2) |
5(2) |
6(2) |
8(3) |
10(3) |
12(3) |
16(3) |
.062 |
.213 |
.043 |
.188 |
.041 |
.165 |
.212 |
.250 |
.188 |
|
|
CSOS |
.093 |
.075 |
.072 |
|||||||||||||||||
|
.138-32(#6-32) |
CSS |
632 |
3(1) |
4(1) |
5(2) |
6(2) |
8(3) |
10(3) |
12(3) |
16(3) |
.062 |
.290 |
.043 |
.250 |
.041 |
.213 |
.289 |
.312 |
.219 |
|
|
CSOS |
.093 |
.075 |
.072 |
|||||||||||||||||
|
.164-32(#8-32) |
CSS |
832 |
3(1) |
4(1) |
5(2) |
6(2) |
8(3) |
10(3) |
12(3) |
16(3) |
.062 |
.312 |
.043 |
.250 |
.041 |
.245 |
.311 |
.344 |
.250 |
|
|
CSOS |
.093 |
.075 |
.072 |
|||||||||||||||||
|
.190-32(#10-32) |
CSS |
032 |
3(1) |
4(1) |
5(1) |
6(1) |
8(2) |
10(3) |
12(3) |
16(3) |
.062 |
.344 |
.043 |
.375 |
.041 |
.290 |
.343 |
.375 |
.281 |
|
|
CSOS |
.093 |
.075 |
.072 |
|||||||||||||||||
|
.250-20(1/4-20) |
CSS |
0420 |
3(1) |
4(1) |
5(1) |
6(1) |
8(2) |
10(2) |
12(3) |
16(3) |
.062 |
.390 |
.043 |
.375 |
.041 |
.354 |
.389 |
.438 |
.375 |
|
|
CSOS |
.093 |
.075 |
.072 |
|||||||||||||||||
All dimensions are in millimeters (Size Unit: mm)
|
METRIC |
Thread Size |
Type |
Thread Code |
Length Code "L" +.0.05-0.13 |
Min.Sheet Thickness |
Blind Mounting Hole Dia |
Min. Depth Of Blind Hole (4) |
Min. Depth Full Thread F |
A |
B Max. |
C |
H |
Min.Dist Hole C/L To Edge |
|||||||
|
Stainless Steel |
||||||||||||||||||||
|
M3X0.5 |
CSS |
M3 |
4(1) |
6(1) |
8(2) |
10(3) |
12(3) |
16(3) |
20(3) |
25(3) |
1.6 |
5.41 |
1.1 |
5 |
1.04 |
4.2 |
5.39 |
6.35 |
4.8 |
|
|
CSOS |
8(3) |
2.4 |
1.91 |
1.83 |
||||||||||||||||
|
M4X0.7 |
CSS |
M4 |
4(1) |
6(1) |
8(2) |
10(2) |
12(3) |
16(3) |
20(3) |
25(3) |
1.6 |
7.92 |
1.1 |
6.5 |
1.04 |
6.23 |
7.9 |
8.74 |
6.4 |
|
|
CSOS |
10(3) |
2.4 |
1.91 |
1.83 |
||||||||||||||||
|
M5X0.8 |
CSS |
M5 |
4(1) |
6(1) |
8(1) |
10(2) |
12(2) |
16(3) |
20(3) |
25(3) |
1.6 |
8.74 |
1.1 |
9.6 |
1.04 |
7.37 |
8.72 |
9.53 |
7.2 |
|
|
CSOS |
2.4 |
1.91 |
1.83 |
|||||||||||||||||
|
M6X1.0 |
CSS |
M6 |
4(1) |
6(1) |
8(1) |
10(2) |
12(2) |
16(3) |
20(3) |
25(3) |
2.4 |
9.9 |
1.91 |
9.6 |
1.83 |
9 |
9.89 |
11.11 |
9.5 |
|
Blind mounting holes may be deeper than minimuns except where sheet material is at or near minimun thickness.
Fasters should always be installed so the flange is flush with the surface of the sheet.
If standoff is used as a bushing, the hole in attached part must not exceed "B" plus .020"/0.51mm.
